Shrimp Brand Oil-Resistant Rubber Hose
Description
Product Construction
-
Inner Tube: Oil-resistant synthetic rubber compound
-
Outer Cover: Special rubber compound with excellent oil and weather resistance
-
Reinforcement: High-tensile fiber braided reinforcement suitable for clamping and pressure resistance
Applications
-
Hydraulic system piping
-
Hydraulic oil transfer
-
Fuel oil transfer
-
Lubricating oil transfer
-
Heavy oil transfer
Technical Specifications
-
Operating Temperature: -30°C to +80°C
-
Working Pressure: 300 PSI
-
Burst Pressure: 3 times the maximum working pressure
Specification Table
| 尺寸 (inch) | 內徑 (mm) | 外徑 (mm) | 工作壓力 (PSI) | 爆破壓力 (PSI) | 層數 | 長度 (尺) |
|---|---|---|---|---|---|---|
| 1/4 | 6.3 | 13 | 200 | 600 | 1B | 330 |
| 5/16 | 8 | 15 | 200 | 600 | 1B | 330 |
| 3/8 | 9.5 | 16.5 | 200 | 600 | 1B | 330 |
| 1/2 | 13 | 21 | 200 | 600 | 1B | 330 |
| 5/8 | 16 | 24 | 200 | 600 | 1B | 200 |
| 3/4 | 19 | 27.5 | 200 | 600 | 1B | 200 |
| 1" | 25 | 35 | 200 | 600 | — | — |
