Shrimp Brand High-Pressure Rubber Air Hose
Description
Product Construction
-
Inner Tube: Styrene-Butadiene Synthetic Rubber (SBR) compound
-
Outer Cover: Special rubber with excellent abrasion and weather resistance
-
Reinforcement: High-tensile fiber braided reinforcement suitable for clamping and high-pressure resistance
Applications
-
CNC machinery
-
Air compressor piping systems
-
Pneumatic tools
-
Civil engineering & construction
-
Shipbuilding and steel industries
-
Compressed air power transmission lines
Technical Specifications
-
Operating Temperature: -30°C to +70°C
-
Working Pressure: 300 PSI
-
Burst Pressure: 3 times the maximum working pressure
Specification Table
| 尺寸 (inch) | 內徑 (mm) | 外徑 (mm) | 工作壓力 (PSI) | 爆破壓力 (PSI) | 層數 | 長度 (尺) |
|---|---|---|---|---|---|---|
| 5/16 | 8 | 16.5 | 300 | 900 | 2B | 330 |
| 3/8 | 9.5 | 18 | 300 | 900 | 2B | 330 |
| 1/2 | 13 | 22 | 300 | 900 | 2B | 330 |
| 5/8 | 16 | 25.5 | 300 | 900 | 2B | 200 |
| 3/4 | 19 | 29.5 | 300 | 900 | 2B | 200 |
| 1" | 25 | 36.5 | 300 | 900 | 2B | 165 |
